Clevis Foundry Hook X-046

Grade 10

Ideal for chains thanks to its clevis design.

Mounting via cotter pin, wide jaw opening, RFID-enabled.

Item No.: X-046

Features

  • Quenched and Tempered Alloy Steel.
  • At least 25% greater WLL than traditional G80 products.
  • Manufactured in accordance with DIN PAS 1061 and ASTM A952/A 952M,EN 1677- 1.
  • Certified by DGUV GS-OA-15-05
  • Design Factor 4:1.
  • Fatigue rated to 20,000 cycles at 1.5 times the WLL.
  • Tempering temperature minimum 400°C
  • Designed for the assembly of chain slings where wide throat openings are necessary.
  • Before using the hook, check whether hooks without safety latches are allowed to be used for the particular application.
